For efficient and precise application of mortar, plaster, or concrete in 3D construction printing, the Wolfpack 3DCP WP Pump & Sprayer is a powerful and versatile solution. Designed to work seamlessly with the WP Continuous Mixer, this pump-sprayer system offers high pressure, controlled flow, and mobility, making it ideal for construction sites, prefabrication workshops, and 3DCP workflows.
Key Features & Advantages
- High-Pressure Delivery
The WP Pump & Sprayer operates at up to 40 bar of pressure, enabling it to pump thick and viscous mortar or concrete mixes with ease. - Strong Motor Power
It is powered by a 4 kW brushless DC motor, ensuring smooth, reliable operation with less maintenance and longer durability. - High Flow Rate
The system can deliver material at a rate of 35 L/min, with adjustable speed from 0 to 260 RPM, allowing flexible control over how fast and thick the output is. - Long Reach
Thanks to its design, the pump can convey mortar up to 25 meters vertically or horizontally — ideal for large job sites or elevation changes. - Durable, Job-Site Ready Construction
The unit includes a robust hopper with a protective grid to keep material flowing without clogging. - Precision Spray Gun
You get a spray gun with three nozzle tip sizes for different applications plus three cleansing balls to help clean out the gun, making it suited for fine or heavy material spraying. - Mobility
The Pump & Sprayer has a compact, mobile frame with rugged wheels, making it easy to transport across job sites. - Included Accessories
Comes with a 10 m mortar hose (25 mm), 10 m air hose, rotor + stator, and a set of nozzles + cleaning balls. - Seamless 3DCP Integration
The WP Pump & Sprayer is designed to integrate directly with the WP Continuous Mixer to create an automated, end-to-end material system — from mixing to application.
Applications & Use Cases
- 3D Construction Printing (3DCP): Pumping mortar or concrete from the mixer into the printhead or feed line.
- Wall Plastering & Stucco: Efficiently spray plaster or stucco onto surfaces with control and consistency.
- Grouting & Repair Work: Inject or spray grout into cracks, voids, or joints with high pressure.
- Masonry & Rendering: Use for rendering facades or performing masonry coating tasks.
- Prefab & Panel Work: Apply mortar to prefabricated panels or architectural elements.
Comparison: WP Pump & Sprayer vs Other Mortar Pumps
Verdict:
If you need high pressure, precise control, and mobility in a mortar pump — especially for 3DCP or spray-based applications — the WP Pump & Sprayer is an excellent choice. Traditional construction pumps may offer good flow, but often lack the pressure or automation flexibility.
Buying (or Renting) Options
- Purchase: Ideal for companies, construction firms, or 3DCP practitioners looking for a long-term, reliable mortar pumping system.
- Rental Option: If you have a project-based need or want to test the system with your mixer setup, ask us about rental or leasing plans (if available).
FAQs
Q1: What kind of materials can the WP Pump & Sprayer handle?
A: It is designed to pump mortar, plaster, grout, and similar cementitious mixes at high pressure.
Q2: How powerful is the motor and what voltage does it use?
A: The pump uses a 4 kW brushless DC motor, and on its specs page requires 220V.
Q3: How far can it pump material?
A: Up to 25 meters vertically or horizontally, which gives you a long reach for high or distant application points.
Q4: What accessories come with the pump?
A: It includes a 10 m mortar hose, 10 m air hose, rotor + stator, spray gun, three nozzle tips, and three cleaning balls.
Q5: Can the pump be moved around easily?
A: Yes. It’s built with rugged wheels and a compact frame for site mobility.
Q6: Does it need to be cleaned often?
A: Yes — with high-pressure material, it’s important to flush and clean after use, especially the hose and spray gun, to avoid clogging.
Q7: Can this be used with 3DCP mixers?
A: Absolutely. It’s designed to integrate with the WP Continuous Mixer, creating a full automated material workflow from mix to application.
Conclusion
The Wolfpack 3DCP WP Pump & Sprayer is a powerful, high-precision mortar pumping system built for modern construction workflows — especially 3D concrete printing, plastering, and rendering. With its high-pressure output, durable motor, long reach, and integration capabilities, it’s a reliable bridge between your mixer and your application job.
Whether you’re building 3DCP walls, spraying architectural coatings, or grouting structural elements, this pump sets a high standard for performance and flexibility.
Contact us today to request a quote, check rental availability, or get a demo of how the WP Pump & Sprayer can transform your workflow.
